ShockWatch RFID
Coming soon! Join our beta program today.
ShockWatch® RFID combines the benefits of RFID inventory tracking with indication of unacceptable handling. Each ShockWatch RFID unit has been fitted with a passive RFID chip which can be scanned with any standard RFID reader to catch damage before it enters the assembly line.
- Reduce damage by 40-60% by implementing a monitoring program that changes behavior
- Easy to add into your current RFID program
- Used by the best supply chains around the world
- No wires or batteries
Based on the impact technology of the ShockWatch 2, ShockWatch RFID is a go/no-go device that will indicate if products have been mishandled during transit or in storage. The indicators are field armable, tamperproof and turn red when an impact beyond a specific threshold has occurred.
Description
SHOCKWATCH 2 FEATURES
- RFID Enabled Impact Indicator
- Easy to add into your current RFID program
- Field-armable
- Tamper-proof
- UHF
- Passive
- Serialized
- No batteries or wires
The ShockWatch 2 is offered as a stand alone or connected indicator:
ShockWatch 2
|
|
SHOCKWATCH RFID APPLICATIONS
- Automotive Parts
- Medical Devices
- Healthcare
- Hospitals
- Electronics
- Packaging
- Logistics and Supply Chain
- Musical Instruments
- Furniture
- Medical Instruments
- Applicances
- Pallets
- Aerospace & Defense
- Glass
- Building Materials
- Warehousing
Imperial
| Sensitivity Range | 5G, 10G, 15G, 25G, 37G, 50G, 75G |
| Duration | 0.5-50 ms |
| Tolerance | ± 15% |
| Operating Temperatures | -13°F to 176°F |
| Shelf Life | 2 years when stored at standard temperature and pressure (68°F, 1 ATM) |
| Size | 1.69 in x 1.69 in x 0.25 in |
Metric
| Sensitivity Range | 5G, 10G, 15G, 25G, 37G, 50G, 75G |
| Duration | 0.5-50 ms |
| Tolerance | ± 15% |
| Operating Temperatures | -25°C to 80°C |
| Shelf Life | 2 years when stored at standard temperature and pressure (20°C, 1 ATM) |
| Size | 42.93 mm x 42.93 mm x 6.35 mm |
Part Numbers
| ShockWatch RFID | 5G SWRFID-5G |
| ShockWatch RFID | 10G SWRFID-10G |
| ShockWatch RFID | 15G SWRFID-15G |
| ShockWatch RFID | 25G SWRFID-25G |
| ShockWatch RFID | 37G SWRFID-37G |
| ShockWatch RFID | 50G SWRFID-50G |
| ShockWatch RFID | 75G SWRFID-75G |
Selection Guide
Imperial
| 5 – 15 ft³ | 15 – 50 ft³ | 50 – 100 ft³ | 100 – 250 ft³ | 250 – 500 ft³ | 500 – 1,000 ft³ | 1,000+ ft³ | |
|---|---|---|---|---|---|---|---|
| 0 –10 lbs | 75G | 75G | 50G | 37G | N/A | N/A | N/A |
| 10 – 25 lbs | 75G | 50G | 50G | 37G | 25G | N/A | N/A |
| 25 – 50 lbs | 50G | 50G | 37G | 25G | 25G | 15G | N/A |
| 50 – 100 lbs | 50G | 37G | 37G | 25G | 15G | 15G | 10G |
| 100 – 250 lbs | 37G | 37G | 25G | 25G | 15G | 15G | 10G |
| 250 – 1,000 lbs | 37G | 25G | 25G | 15G | 15G | 10G | 10G |
| 1,000 – 2,000 lbs | 25G | 25G | 25G | 15G | 15G | 10G | 5G |
| 2,000 – 5,000 lbs | 25G | 25G | 15G | 15G | 10G | 10G | 5G |
| 5,000 – 10,000 lbs | 25G | 15G | 15G | 15G | 10G | 10G | 5G |
| 10,000 – 15,000 lbs | N/A | 15G | 15G | 10G | 10G | 5G | 5G |
| 15,000 – 20,000 lbs | N/A | N/A | 10G | 10G | 5G | 5G | 5G |
| 20,000 – 30,000 lbs | N/A | N/A | N/A | 5G | 5G | 5G | 5G |
| 30,000+ lbs | N/A | N/A | N/A | N/A | 5G | 5G | 5G |
Metric
| .14-.42m³ | .42-1.42m³ | 1.42-2.83m³ | 2.83-7.08m³ | 7.08-14.16m³ | 14.16-304.8m³ | 304.8+m³ | |
|---|---|---|---|---|---|---|---|
| 0-5 kg | 75G | 75G | 50G | 37G | N/A | N/A | N/A |
| 5-11 kg | 75G | 50G | 50G | 37G | 25G | N/A | N/A |
| 11-23 kg | 50G | 50G | 37G | 25G | 25G | 15G | N/A |
| 23-45 kg | 50G | 37G | 37G | 25G | 15G | 15G | 10G |
| 45-113 kg | 37G | 37G | 25G | 25G | 15G | 15G | 10G |
| 113-454 kg | 37G | 25G | 25G | 15G | 15G | 10G | 10G |
| 454-907 kg | 25G | 25G | 25G | 15G | 15G | 10G | 5G |
| 907-2,268 kg | 25G | 25G | 15G | 15G | 10G | 10G | 5G |
| 2,268-4,536 kg | 25G | 15G | 15G | 15G | 10G | 10G | 5G |
| 4,536-6,804 kg | N/A | 15G | 15G | 10G | 10G | 5G | 5G |
| 6,804-9,072 kg | N/A | N/A | 10G | 10G | 5G | 5G | 5G |
| 9,702-13,608 kg | N/A | N/A | N/A | 5G | 5G | 5G | 5G |
| 13,608+ kg | N/A | N/A | N/A | N/A | 5G | 5G | 5G |
Accessories
Alert StickerThis unmistakable alert affixes directly to the bill of lading to caution the carrier and consignee that the shipment is being monitored for mishandling. |
Alert TapeShockWatch packing tape provides an unmistakable visual alert that impact indicators are in use and reinforcement that proper handling procedures are required. |
Companion LabelA companion label provides a visual warning that the package is being monitored and has instructions on what to do should mishandling occur. |
