MAG 2000
The ShockWatch MAG 2000 impact indicator is a cost-effective, resettable and reusable device designed to monitor the handling of fragile goods and freight containers greater than 500 lbs. The device is also widely used on rail cars and trucking fleets to monitor for excessive impacts during humping or latching.
The MAG 2000 utilizes two tuned and highly sensitive magnets. When an out-of-tolerance impact is experienced, the magnets are forced out of alignment clearly indicating the angle and severity of impact. A uniquely designed key is supplied to unlock the cover on the unit. This key allows the product to be reset after activation and resists tampering.
Description
MAG 2000 FEATURES
- Resettable and reusable
- Tamper resistant
MAG 2000 APPLICATIONS
- Auto and Truck Parts
- Electronics – Computer Hardware
- Textiles
- Glass
- Consumer Products
- Construction – Supplies and Fixtures
- Energy and Utilities
- Metal Fabrication
- Railroads
- Consumer Electronics
- Equipment Rental
- Auto and Truck Manufacturers
- Scientific and Technical Instruments
- Biotechnology and Drugs
- Industrial Equipment
- Medical Devices and Supplies
- Logistics / Transport and Storage
- Electronics – Telecommunications
- Aerospace and Defense
- Furniture and Fixtures
Imperial
| Sensitivity Range | 0.5 – 20G (in 0.5G increments) |
| Duration | 0.5 – 50 ms |
| Tolerance | ± 10% |
| Operating Temperature | -4°F to 140°F |
| Shelf Life | 2 years |
| Size | 2.5 in x 2.4 in x 0.79 in |
Metric
| Sensitivity Range | 0.5 – 20G (in 0.5G increments) |
| Duration | 0.5 – 50 ms |
| Tolerance | ± 10% |
| Operating Temperature | -20°C to 60°C |
| Shelf Life | 2 years |
| Size | 63.5 mm x 60.96 mm x 20 mm |
Part Numbers
| MAG 2000 Single Unit (“x” is G value desired; 0.5G to 20G) | M21-xG |
| MAG 2000 Single Unit with Adhesive Backing (“x” is G value desired; 0.5G to 20G) | M21A-xG |
| MAG 2000 Single Unit with Bracket (“x” is G value desired; 0.5G to 20G) | M22-xG |
| MAG 2000 Single Unit with Foam Adhesive & Bracket (“x” is G value desired; 0.5G to 20G) | M22A-xG |
| MAG 2000 Two Units with Foam Adhesive & Bracket (specify G value when ordering) | M23A |
Accessories
Alert StickerThis unmistakable alert affixes directly to the bill of lading to caution the carrier and consignee that the shipment is being monitored for mishandling. |
Alert TapeShockWatch packing tape provides an unmistakable visual alert that impact indicators are in use and reinforcement that proper handling procedures are required. |
Companion LabelA companion label provides a visual warning that the package is being monitored and has instructions on what to do should mishandling occur. |
